Illinois State Plumbing Practice Exam

These questions are part of the practice quiz. Start practicing

• For a 1 1/4 inch pipe, the maximum distance from fixture trap to vent is?
• What is the minimum depth of a trap seal for any above-ground plumbing fixture?
• What is the drainage fixture units for a shower?
• What is the primary function of the venting system in a drainage setup?
• All vent and branch lines shall be installed so that they drain where?
• Faucet washers requiring replacement in a kitchen sink faucet may indicate wear on which part of the faucet?
• True or False: The maximum distance between manholes on underground drainage lines that are 10 inches in diameter or larger is 150 feet.
• What is the minimum trap size for a water closet?
• Where is the corporation stop located on a water service line?
• What chemical prevents oxides on copper before soldering?
• Which device protects water quality, is failsafe in design, and isolates a heat exchanger when the water pressure and exchange medium drop below a preset level?
• Clothes Washer minimum trap size is specified as?
• Which factor is considered when sizing vent piping?
• Which device in venting system helps prevent back-pressure and siphonage, protecting traps?
• What is created when air pressure drops below atmospheric pressure?
• Copper Type M is allowed to be installed for water piping in which location?
• What is the measurement called when you measure from the inside wall of a pipe to the opposite inside wall?
• Which type of drain is designed to collect surface water around a building and prevent entry into the interior?
• In drainage venting, which vent extends above the highest drain on the stack to allow air entry?
• Which fitting is used to secure a wall-mounted toilet?
• What are devices for supporting and securing pipes, fixtures, and equipment to walls, ceilings, floors, or other structural members called?
• Which section of a building's drainage system is located at the lowest point and receives discharge from soil, waste, and other interior drain pipes?
• What is the drainage fixture units for a water closet?
• True or False: The vent for a single water closet is at least 2 inches in diameter.
• Which gas is lighter than air in plumbing?
• What term describes reverse flow in a water supply caused by a vacuum?
• Which backflow prevention device is used in plumbing to prevent backflow of non-potable liquids into the drinking water system?
• Corrosion inside pipes can cause tuberculation, which forms small hemispherical lumps on the pipe walls. What is this condition called?
• Which type of gas used in plumbing is lighter than air?
• What is the minimum trap size for a kitchen sink?
• What is the maximum distance between manholes on underground drainage lines with a diameter of 10 inches or larger?
• What is the minimum trap size for a shower?
• Which waste is known to include toxic liquids such as ethylene glycol and refrigerants?
• The discharge line on a sewage ejector line requires which device?
• What is the minimum size of a gas and oil interceptor?
• Under what circumstances may a saddle valve be used to connect an icemaker or refrigeration line?
• The finished exterior size of a shower in a single-family home must be at least how many inches?
• What portion of a fixture drain lies between the trap and its vent?
• What is the maximum temperature of any water discharging into any part of the drainage system?
• In plumbing, if piping, fixtures, or equipment would interfere with the operation of windows or doors, what action is required?
• A buried water supply is accessed by which device designed to deliver water from the street main?
• What is the maximum drainage fixture units for a horizontal branch using a 4-inch pipe?
• Which outdoor fixture provides a direct hose connection to the water supply?
• What type of joint can be disassembled and reassembled without removing any adjacent piping?
• True or False: A temperature and pressure relief valve shall discharge to the outside atmosphere if a floor drain is accessible.
• Which system is specifically designed to remove rainwater and ground water from a building site?
• Water closet bowls for public use shall be of what design?
• Which factors affect vent size?
• For a vertically installed cast iron pipe, what is the maximum allowable distance between supports?
• Clothes Washer Drainage Fixture Units (DFU) value is?
• What term describes the measured length along the center line of the pipe including its fittings?
• Tanks flushing more than one urinal require what type of operation?
• Bath tub Drainage Fixture Units (DFU) value is specified as how many DFU?
• Which of the following is NOT an acceptable bidet water configuration?
• In plumbing, what term describes the rapid rise in pressure caused by a sudden stop in flow in a pipe?
• Water Heaters, Water Coolers, Drinking Fountains, Heat Exchangers, and Water Treatment Equipment are examples of which category?
• Which type of potable water supply provides water for drinking, culinary, and sanitary purposes for an owner-occupied single-family dwelling?
• Which fitting is required for making the yoke vent intersection?
• In a high-pressure water system, which component is used to reduce incoming pressure?
• For a lavatory, what is the Drainage Fixture Units at a 1-1/4 inch trap size?
• What is the name of the point at which impounded liquid will overflow a fixture or receptacle?
• What is the required trap seal depth for above-ground fixtures?
• Which valve operates by screwing a disc against a seat?
• Which vent type is used to relieve pressure by allowing air movement between drainage and vent systems?
• Which device is used to join two pipe sections and allow disassembly without cutting?
• Which device is used on a sewage ejector discharge line to prevent backflow into the building?
• Which type of sewer system is not directly controlled by a public authority?
• All showers and shower-baths must be provided with what type of device?
• Which value is correct for gallons per minute per fixture unit?
• Minimum vent size for a 4-inch trap?
• Which term describes the network that provides potable water to a single dwelling including the service line?
• What is a vent that permits circulation of air in between drainage and vent systems?
• What type of vent receives the vapors from non-pressure sterilizers or the exhaust vapors from pressure sterilizers and conducts them to the outside atmosphere?
• Bath Tub minimum trap size is required to be what size?
• What is the maximum number of water closets on a 3-inch horizontal branch drain?
• What is the lowest part of the internal cross section of a pipe called?
• True or False: A 3-inch horizontal branch drain may accommodate two water closets.
• What is the minimum trap size for a urinal?
• What is the maximum developed length for an indirect waste to any sanitary waste line?
• Water Heaters, Water Coolers, Drinking Fountains, Heat Exchangers, and Water Treatment Equipment belong to which category?
• What fitting is acceptable for connecting two horizontal drain lines?
• What phenomenon occurs when there is a sudden deceleration of water flow in a closed conduit?
• What is the minimum size for the vent for a single water closet?
• What is the minimum pipe size for a maximum size of any combination waste and vent drainage line?
• Which term describes joining plastic pipe to fittings by chemical fusion?
• What is the maximum distance allowed between trapped openings on a trench drains used to carry waste to gas and oil interceptors?
• A 45-degree bend represents which fraction of a circle?
• Which device directly transfers heating energy to a space by radiation or gravity convection?
• Which organization lists the approved standards for gas-fired storage type water heaters?
• What is the maximum Drainage Fixture Units (DFUs) allowed on a 2-inch horizontal waste line?
• The tube attached to the ballcock and discharging into the toilet tank is designed for what purpose?
• What is the minimum size of a cleanout serving a 4-inch drain line?
• Which type of sewer system is used for conveying rain water, surface water, ground water, or condensation from the building storm drain to an approved point of discharge?
• Where is copper type M allowed to be installed for water piping?
• What is the minimum finished exterior size of a shower in a single-family home?
• True or False: The minimum constant pressure on the discharge side of the water meter is 20 psi.
• What happens when different materials are joined in a water piping system?
• What device controls the water temperature maintained in a hot water tank for single-family use?
• Indirect waste to sanitary waste line maximum developed length is how many feet?
• Where is an escutcheon ring used?
• Which valve type meets the requirement for shower mixing to regulate temperature and pressure?
• The trench shall be backfilled in 6" layers to how many inches above the top crown of the piping?
• Which of the following is the correct minimum vent pipe height above the roof?
• Which part of the waste stack extends above the highest horizontal drain connected to the stack?
• Which term designates the section of the fixture drain that runs from the trap to the vent?
• Which faucet is designed to connect a garden hose to the water supply?
• What is the drainage fixture units for a kitchen sink?
• What is the function of the siphon breaker hole near the top of a dip tube?
• What is the drainage fixture units for a urinal?
• In plumbing terminology, what is the vertical water supply pipe that carries water to main branches called?
• Floor Drain Drainage Fixture Units (DFU) value is?
• Which style of water closet typically uses the least water in its trap?
• A 22.5-degree bend represents which fraction of a circle?
• What is the minimum clearance required in front of a cleanout?
• For a 4 inch pipe, the maximum distance from fixture trap to vent is?
• How many gallons per minute are equivalent to one fixture unit?
• Lavatory minimum trap size is specified as?
• Which section of piping is located at the lowest point of a building's drainage system and receives discharges from interior drainage?
• Piping and fixtures for standards not adopted by the Code may be installed with permission from which agency?
• In which type of plumbing fixture may a magnesium rod be installed?
• What type of drain is placed outside a basement entryway or paved driveway?
• True or False: A temperature and pressure relief valve shall discharge to the outside atmosphere if a floor drain is not accessible.
• For a 2 inch pipe, the maximum distance from fixture trap to vent is?
• A waste pipe that discharges into and through an approved open connection is called what?
• What is the name of a water supply pipe that extends vertically one full story or more to supply water to main branches or a group of fixtures?
• What is the unobstructed open edge of a fixture called?
• What is the minimum height above the flood rim at which a relief vent shall connect to the vent stack?
• The Durham System is defined as a waste system where all piping is threaded and uses recessed fittings.
• To which side of the trap must the overflow pipe connect?
• What is the minimum size specified for any combination waste and vent drainage line, in inches?
• Backfill height 18 inches? The trench backfilled in 6" layers to how many inches above the top crown?
• A vent connecting one or more individual vents with a vent stack is called what?
• Which professional is qualified to field test all backflow prevention devices?
• Where must the pump be installed on a whirlpool type bathtub?
• Which fitting is acceptable for connecting two horizontal drain lines?
• What is the maximum drainage fixture units for a horizontal branch using a 2-inch pipe?
• For a 1 1/2 inch pipe, the maximum distance from fixture trap to vent is?
• What fitting is used to secure a wall-mounted water closet?
• A waste pipe that discharges into an approved open connection is called what?
• What is the minimum time required for an acceptable test of the water piping system?
• Which type of device or fixture receives the discharge from indirect waste pipes?
• Which device prevents excessive vacuum in a pressure vessel?
• A pipe making an angle greater than 45 degrees from horizontal is called what?
• The substance used to prevent oxide formation on freshly cleaned copper before soldering or brazing is called what?
• A 90-degree bend represents which fraction of a circle?
• The two parts of a trap used to measure the depth of the trap seal?
• What is the minimum height above the roof that a vent pipe must extend?
• What is required for a water piping system with a pressure exceeding 80 psi?
• In residential plumbing, which piping system includes the water service and all potable piping to supply a single dwelling?
• True or False: Mechanical Devices shall not be installed in the plumbing vent system except for single family structures where the homeowner is doing their own plumbing work.
• Which faucet drains water from the bottom of a water heater?
• Which type of venting applies only to floor drains which depend on siphonage for proper operation?
• For a 3 inch pipe, the maximum distance from fixture trap to vent is?
• Peppermint test is used to find defects in which system?
• What process fuses plastic pipe and fittings together chemically?
• Floor Drain minimum trap size is specified as?
• Minimum vent size for a 4-inch trap?
• What is the name of the plumbing inspection conducted before covering walls and floors?
• Which test is used to identify defects in the drainage system?
• At which trap size does lavatory DFU increase to 2 DFU?
• What type of waste includes harmful substances such as ethylene glycol, hydrocarbons, oil, refrigerants, or hydrazine?
• What type of receptacle receives sanitary or storm waste located below the normal grade level of the gravity system?
• Which vent rises as near as possible to or above the highest water level in the fixture vented before connecting to the stack or main vent?
• Who is qualified to field test all backflow prevention devices?
• To properly tighten a mission band or Fernco coupling, the torque wrench should be set to which pressure?
• What type of faucet is used for drawing water from a buried pipe?
• Which statement about saddle valves is true?
• What is the maximum vertical distance between a fixture outlet and the trap weir?
• What is the purpose of the hole near the top end of a dip tube in a domestic water heater?
• Which type of waste contains human excrement and liquid waste?
• A protective strainer is required on the upstream side of the first check valve unless it is what type of system?
• What is the minimum constant water pressure on the discharge side of the water meter?
• An escutcheon ring is typically used around what feature?
• Tuberculation is a corrosion-related condition inside piping. It most directly affects which part of the pipe?
• Which device isolates a heat exchanger when pressure drops below a preset level to protect water quality?
• A magnesium anode rod is typically installed in which appliance?
• Which type of vent connects a drain pipe through a fitting at an angle less than 45 degrees?
• Which piping joint is designed to connect two sections while allowing easy disassembly without disturbing adjacent piping?
• Backflow devices must be installed in a way that they are protected from which conditions?
• Which two parts of a trap are used to measure the depth of the trap seal?
